Hornet HP 3.5" Select Square

Lensed Downlight Select
Lensed Downlight Select

The Hornet® family of downlights offers high performance in a compact 3.5" size. The Hornet® HP is available in various styles including Downlight, Adjustable, Pinhole Adjustable, Pinhole Adjustable Slot, and Shower Trim. There are also Lensed Downlight and Lensed Wall Wash options, as well as the new lensed Hornet® Select Downlight available in round or square apertures, which provides increased lumen output at an affordable cost. Additionally, there are Remodeler and Trimless options available.

Products marked with PoE logo will be compatible for use with PoE, consult factory for compatible systems.

Features & Benefits

Wattage

30 max

Lumen Output

2,773 max

Candle Beam Center Power (CBCP)

12,503 max

Color Temp (CCT)

2200K , 2700K , 3000K , 3500K , 4000K , Class A (Full Gamut) , Crisp White (Full Gamut) , Dim to Warm

Color Rendering Index (CRI)

80+ , 90+

Technology

Fixture Modification Request (EDR)

Content & Downloads

Product
Technology
Aperture Size
Trim / Trimless
Wattage
Delivered Lumens
SPEC Sheets
IES Files
REVIT Files
Install Sheets
Downlight
Technology
Aperture Size3.5"
Trim / TrimlessY / Y
Wattage13, 18, 20
Delivered Lumens1,305 max
IES Files
INSTALL Sheets
REVIT Files
SPEC Sheets
Adjustable
Technology
Aperture Size3.5""
Trim / TrimlessY / Y
Wattage13, 18, 20
Delivered Lumens1,300 max
IES Files
INSTALL Sheets
REVIT Files
SPEC Sheets
Pinhole Adjustable
Technology
Aperture Size3.5"
Trim / TrimlessY / Y
Wattage13, 18, 20
Delivered Lumens1,181 max
IES Files
INSTALL Sheets
REVIT Files
SPEC Sheets
Shower
Technology
Aperture Size3.5"
Trim / TrimlessY / N
Wattage13, 18, 20
Delivered Lumens-
INSTALL Sheets
REVIT Files
Drop Glass
Technology
Aperture Size3.5"
Trim / TrimlessY / N
Wattage13, 18, 20
Delivered Lumens1179 max
IES Files
INSTALL Sheets
REVIT Files
SPEC Sheets
Lensed Downlight
Technology
Aperture Size3.5"
Trim / TrimlessY / Y
Wattage9, 12, 16, 23, 27, 30
Delivered Lumens2,773 max
INSTALL Sheets
REVIT Files
SPEC Sheets
**NEW** Lensed Downlight Select
Technology
Aperture Size3.5"
Trim / TrimlessY / Y
Wattage9, 12, 16, 23
Delivered Lumens2369 max
IES Files
INSTALL Sheets
REVIT Files
SPEC Sheets
Lensed Wall Wash
Technology
Aperture Size3.5"
Trim / TrimlessY / Y
Wattage9, 12, 16, 23, 27, 30
Delivered Lumens2,659 max
IES Files
INSTALL Sheets
REVIT Files
SPEC Sheets
